All right. So, in my past videos, I have

been mostly focused on analyzing, you

know, other traders. I've been focused

on the actual strategies and kind of

just been testing and vibe coding and

trying to figure out, you know, and

learning about poly markets. But now

it's time to take things on a little bit

more big picture stuff. we actually need

to figure out the overall solution

design and and architecture of the the

bots and I think I I don't think I'm

sure that this will make like the whole

software the whole bot much more robust

and actually better performing uh in the

future. So in this video I have designed

the complete uh architecture in like a

big picture way. So with these diagrams,

so I'm going to go through it and of

course you can copy this or you can use

this for inspiration in your own but of

course I encourage you if you have any

ideas or if you see any flaws in this

design to you know leave a comment down

below and then I can refine uh this this

bot here. So let me start from the from

the top from the from the in the

beginning of the bot. Of course we have

what I call the the config loader and

this is basically just all the settings

that we're going to have in our bot. The

settings can be different things such as

the different strategies, what kind of

data that we need and uh different you

know settings. A relatively easy and

simple way to configure the bot before

we click play basically. And then we

have the different data sources that I

will be uh referring to as pipelines.

So this can be for example most

important is the market channel

websocket from poly markets and we have

the user channel websocket and other you

know channels. The idea behind this is

we that we are able to connect several

different data sources into our bot and

then make you know actions based on

those uh data sources. It could also be

for example the weather in Canada or it

could be you know how many times you

know Elon Musk tweet tweets per day and

so and you know stuff like that. So any

kind of data uh we get that into the

data sources.

So when we get the data it's just the

raw data that we receive into our butt

and then we have these pipeline

adapters.

So, so what they do is they basically

just take the data and then they tag it

and you know the specific details I'm

not sure about yet. So this is just an

an overview and sort of an idea of how

to go about this. So it could be

something like the the the a timestamp

of when it's received what kind of

source is it the poly markets websocket

and then what kind of a event it is in

this case the event type price change as

an example. So this is what we call the

tagged message

that's then passed over to our

processing unit.

The processing unit has again different

uh methods to process the actual data.

So you can see here in the tag message

we still have the raw data from our

pipelines from before. So we haven't

touched that yet. Now the processing

units uh task is basically to take this

data the raw data from the event. For

example, it could be a price change or

it could be you know a change to the

order book. It's going to take that data

and then convert it to you know a format

that we can use in our bot because you

have to consider that let's say we have

10 different data sources that all

return let's say a price of some kind.

Well, we need to make sure that all the

fields and so on and so forth has the

correct format. And so basically just

unifying the the format so we can use

that in in the rest of of our our

program.

So so that's what I call the processed

event. Okay. So we get the raw data in,

we tag the data and then we process it.

We then pass it over to our event bus.

So the task of the event bus is

basically just to to orchestrate

the different events that we have to the

different signals. So for example, let's

say that we have a simple moving average

strategy. Let's say a crossover of 14

SMA over you know 28 SMA. That's a

signal that we register in our bot. And

this signal then subscribes to the

specific events that it needs. Let's say

we have uh 10 different sources, but

this one we only need this one only need

to subscribe to let's say the BTCUSD

uh data source.

So that so that's uh this event bus's um

you know responsibility to basically

forward the processed event over to our

signal signal layer that has the

different signals. Okay.

Now the signal layer's responsibility is

then producing the signal. So for

example, it could be the exponential

moving average. Okay. So it then takes

the event and then it it computes the

signal.

In this case, it's the exponential

moving average, different kind of

periods and so on.

It passes that data

over to our strategy layer.

So, this is kind of where I'm not sure

if this makes this spot a little bit

different, but the bot will be able to

actually have several different

strategies in one. So, it can subscribe

to several different markets, but also

have different strategies. So, we have

different strategies that also subscribe

to different signals. So, you see the

strategies subscribe to signals, the

signals describe subscribe to events and

so on.

And the strategy is then you know that's

where we formulate the actual strategy.

For example, the moving average

crossover or whatever strategy that we

you know figure out and that produces

actions.

Again the details here is not clear yet.

It's just an overview and it produces an

action payload. For example, it can be

the buy action to buy, you know, uh

whatever for an amount and then a reason

and other data that we deem fit for for

the action um payloads here.

It then moves over to the execution

layer. So this is where the you know

this is where we actually make the

orders. So, we have some validation and

maybe some locking. Again, a little bit

fluffy about the details here. And then

we have a a risk manager. So, um I'm not

sure exactly how I'm going to go about

this yet because I'm also thinking about

implementing methods to control the

risks uh within the strategies. For

example, if we have let's say we have

three or four different strategies

actually the same strategy

but maybe with different risk profiles

and we want to you know test that

then we need some kind of a risk uh

module on the strategy layer and uh and

so this risk manager is potentially just

a portfolio risk manager like an overall

uh risk manager. So I need to think

about that a little bit more. And then

we have the execution. So the actual you

know do we take the action go through

all these steps and then we execute it.

After we execute the trade this is kind

of this is what I've just been kind of

thinking about is well how do we

actually manage it then? How do we

because the strategies probably also

need to know when to exit. For example

let's say that all right we place a a

buy. First of all, we need to monitor is

it getting filled and if not then what

are we going to do unless the poly

market client handles handles it for us

but in case it doesn't and in case we

have to manage that manually well we

have to figure that out and I do have a

solution for that I'm going to explain

and then we also have to manage let's

say we need to close

um positions maybe we need to sell

positions based on the definition in the

strategy Okay.

So

this is where if we go back to the top

uh to the data sources, this is where

the user channel websocket comes in and

potentially other methods. So we

actually take that data

um the the order data for the specific

user in our case you know our you know

portfolio because we can subscribe to

websockets as well. So for example when

an order is filled we get that in as an

event from the websocket. We manage it

just like we did before and we process

it and so on and so forth. But the

difference is it doesn't go to the

signal layer. instead it goes to our

position layer. So we need a a way let's

see if you can see it. So we need um a

place in our our bot to uh handle state

of the the positions. So, so that will

receive uh events from the use event

pipeline and then it will keep local

state and I'm thinking also a way to

synchronize. Let's say that let's say

that we lose connection of of the

websocket for 2 seconds and in that

period of time we had a trade execute.

then we need a way to uh synchronize and

then we can utilize

another

pipeline which could just be an you know

a an API call that just polling every I

don't know 5 seconds every second or

whatever the rate limit allows us to

pull.

So the position layer then enables us to

um yeah just to keep a track of the

positions and so on. And we can also

have our

we can also have our strategies

subscribe to

the for example the user channel web

socket. So let's say we subscribe to the

market channel which gets all the you

know price updates for the market but

also the user channel. So let's say we

subscribe to the market channel. We

figure out all right now we want to buy.

We then make an action to buy

and then when it's filled, we get the

event from the the user channel here all

the way down through here through the

event bus and then to the signal layer.

Now,

this is where I'm not 100% sure yet

because we probably don't want to have a

signal specifically for

uh like all right now this order has

been filled. So we potentially need

this event bus to also just relay it

directly to uh the strategy layer.

Not sure yet. So this is need to think

about this a little bit more. So of

course if you have some suggestions how

to solve that or if you have some ideas

um how to improve this then please let

me know down in the comments below. And

um the next step will then be to

implement all these different modules.

And I've already begun working on the

the the pipelines here, the pipeline

adapters, the processing unit,

and then part of the event bus. I'll be

making a video about that when the code

looks good and when it's um you know,

when it's in a good order. So, I expect

that uh video to be ready hopefully um

hopefully tomorrow. So, I hope you check

in uh tomorrow and subscribe to receive

notification next time I post a video.

So, see you on the next video. Have a

good one. Bye.
